उत्पत्ति के प्लेस:
चीन
ब्रांड नाम:
WINNER
प्रमाणन:
ISO9100
मॉडल संख्या:
BC010
वीडियो
वीडियो
वीडियो
Gold-plated Beryllium Copper Wire is a high-strength copper alloy containing a small percentage of cadmium, which significantly enhances its mechanical properties while retaining good electrical conductivity. This wire is primarily used in applications where both electrical conductivity and high tensile strength are required.
| Specific Resistivity | 7.68 µOhm·cm²/cm |
| Commercial Resistance Tolerance (On Sizes below 0.020) | 3.00 % |
| Thermal Electromotive Force (EMF) Vs Copper | -0.014 |
| Specific Resistance | 46.200 Ohm·cm/ft |
| Temperature Coefficient of Resistance (0 to 100 Degree Celsius (ºC) Temperature) | 0.0015 Ohm/Ohm/ºC |
| Density | 8.25 g/cm³ |
| Youngs Modulus | 18 x 106 psi |
| Specific Heat at 20 Degree Celsius (ºC) Temperature | 0.100 cal/g |
| Thermal Conductivity | 1.069000 W/cm/ºC |
| Coefficient of Linear Expansion | 17.6 x 10-6 in/in ºC |
| Melting Point | 865.00 ºC |
